一般来说,
济南彩钢房渗水主要是由于自攻螺丝、彩钢板搭接、屋面瓦、铆钉、人在房内造成彩钢板变形、装饰件防雨胶脱落等。比如采光窗。对应的泄漏可分为以下几点:
Generally speaking, the water seepage of Jinan color steel room is mainly caused by self tapping screws, color steel plate lapping, roof tiles, rivets, color steel plate deformation caused by people in the room, and rainproof glue falling off of decorative parts. Such as daylighting windows. The corresponding leakage can be divided into the following points:
房间内螺丝、紧固件泄漏
Leakage of screws and fasteners in the room
这种现象主要发生在双层彩板和单层彩钢房。在施工过程中,自攻胶垫会因自攻力过大、过轻、自旋偏斜、歪斜等原因造成片材变形、脱落或形成凹痕,从而产生凹痕或凹痕。此外,自攻位置不正确,错开彩钢板下檩条直接形成孔洞也是漏水的重要原因之一。在没有保温系统的单层彩板的房屋结构中,这种漏水可能并不明显,主要是因为雨水渗入钢板接触檩条的部分后,雨水不一定会迅速滴落。
This phenomenon mainly occurs in double-layer color plate and single-layer color steel room. During construction, the self tapping rubber pad will cause sheet deformation, falling off or forming dents due to excessive self tapping force, light weight, spin deflection, skew and other reasons, resulting in dents or dents. In addition, the incorrect position of self tapping and the direct formation of holes by staggering the purlins under the color steel plate are also one of the important reasons for water leakage. In the building structure with single-layer color plate without thermal insulation system, this kind of water leakage may not be obvious, mainly because the rainwater may not drip rapidly after penetrating into the part where the steel plate contacts the purlin.
水平搭接和垂直搭接,彩钢板搭接处漏水,彩钢板瓦波过低或雨水量过大,容易造成漏水,彩钢板搭接接头漏水,容易形成大面积漏水,多发生在弧形房间。造成这种现象的主要原因是两板搭接不紧,自攻螺纹未满。
Horizontal lap and vertical lap, water leakage at the lap joint of color steel plate, low tile wave of color steel plate or excessive rainfall, easy to cause water leakage, water leakage at the lap joint of color steel plate, easy to form a large area of water leakage, mostly in arc-shaped rooms. The main reason for this phenomenon is that the two plates are not lapped tightly and the self tapping thread is not full.
在轻钢结构房屋的建造中,脊瓦漏水也是比较普遍的现象。在雨季,尤其是雨水量大的时候,雨水会从脊瓦上溅出。在了解了彩板房的结构、可能的漏水点以及漏水的原因后,我们再讨论解决办法。根据多年的施工经验,提出渗漏方案:
In the construction of light steel structure houses, the leakage of ridge tiles is also a common phenomenon. In the rainy season, especially when there is a large amount of rain, rain water will splash from the ridge tiles. After knowing the structure of the color board room, the possible water leakage points and the causes of water leakage, we will discuss the solutions. Based on years of construction experience, the leakage scheme is proposed:
该方案可使彩钢板房形成整体防水层,城市防水使用自粘卷材。自粘卷材是一种防水密封材料,可以自行粘合在基面上。分为带胎不干胶和不带胎不干胶两种。它是由轮胎自粘上、下自粘胶夹在胎基上组成,上覆盖面为乙烯基薄膜,下覆盖面为可剥离的硅油膜。
This scheme can make the color steel plate room form an integral waterproof layer, and it is recommended to use self-adhesive coiled material for urban waterproof. Self adhesive coiled material is a kind of waterproof sealing material, which can be bonded to the base surface by itself. There are two types of adhesive with tire and adhesive without tire. The utility model is composed of a tire self-adhesive upper and lower self-adhesive clamps on the tire base. The upper coverage is a vinyl film and the lower coverage is a peelable silicone oil film.
它由不干胶、上乙烯基膜和下硅油膜组成。本产品具有自愈性,即当遇到穿孔或嵌入硬物时,线圈会自动与这些物体融合,仍保持良好的防水性能。产品详情及特点见:橡胶沥青自粘防水卷材
It consists of self-adhesive, upper vinyl film and lower silicone oil film. This product has self-healing property, that is, when encountering perforation or embedded hard objects, the coil will automatically fuse with these objects and still maintain good waterproof performance. See rubber asphalt self-adhesive waterproof coiled material for product details and features
对房间螺丝、紧固件、彩钢板、脊瓦的搭接接头进行防水处理。其施工流程为:清洗基层→涂刷基层处理防水材料→添加加强层施工→涂刷防水涂料。
Waterproof the lap joints of screws, fasteners, color steel plates and ridge tiles in the room. The construction process is as follows: cleaning the base course → painting the base course treatment waterproof material → adding the reinforcing layer construction → painting the waterproof coating.
